KKSB Pi 5 Case for DAC+/DAC Pro – RCA side and Ethernet/USB ports

KKSB Case for Raspberry Pi 5 and Raspberry Pi DAC+ and DAC Pro Sound Cards

Name: KKSB Case for Raspberry Pi 5 and Raspberry Pi DAC+ and DAC Pro Sound Cards
Brand: KKSB Cases
SKU: 7350001161785
Price: 16.9 EUR
Availability: OutOfStock
Rating: 5.0 (2 reviews)

€16,90

Sold out

SKU 7350001161785

This Raspberry Pi 5 Case from KKSB Cases has been designed to complement the audio capabilities of Raspberry Pi 5 setup. This case fits IQaudio DAC Pro and IQaudio DAC+ sound cards for Raspberry Pi.

Note: This listing is for the KKSB Case only. Raspberry Pi 5, Sound Cards, KKSB DIN Rail Mount Clip, Addons, GPIO Cable and Electronics are NOT included.

Sold-out

Technical Details

Compatible board: Raspberry Pi 5
Compatible HATs: Raspberry Pi DAC Pro, Raspberry Pi DAC+, IQaudio DAC Pro, IQaudio DAC+
Port access: 1 × USB-C (power), 2 × micro-HDMI, 2 × USB 3.0, 2 × USB 2.0, 1 × Gigabit Ethernet, 2 × RCA (L/R) and 3.5 mm headphone jack cutouts for the sound card, microSD card opening, side access for a 40-pin GPIO cable
Power button: External button integrated in the case, marked with a power symbol
Cooling: Ventilation slots in both side panels; fits the official Raspberry Pi 5 Active Cooler or similar coolers (included stackable header and 20 mm spacers leave airflow between cooler and sound card)
Material: Sandblasted black anodized aluminium with powder-coated steel frame
Mounting: 2 keyholes on the bottom for wall mounting; base compatible with KKSB DIN Rail Mount Clip (sold separately); threaded holes for the KKSB Camera Holder; rubber feet
Package dimensions: 115 × 75 × 65 mm; shipping weight 220 g
In the box: Case, M2.5 20 mm male-female hex standoffs, 40-pin stackable header, rubber feet
Not included: Raspberry Pi 5, sound card, KKSB DIN Rail Mount Clip, GPIO cable
EAN: 7350001161785

User Manuals

Worldwide shipping
EU delivery: ~ 3-8 days,
Outside the EU: ~ 7-15 days.

Pay using Paypal or Bank Card
We also accept bank payment for larger orders

AI-generated backgrounds are used in some images · Learn more

3D model / Dimensions

KKSB Pi 5 Case for DAC+/DAC Pro – under a TV in a living room

KKSB Pi 5 Case for DAC+/DAC Pro – end with power button against a dark background

KKSB Pi 5 Case for DAC+/DAC Pro – Ethernet and USB end against a dark background

KKSB Pi 5 Case for DAC+/DAC Pro – in a recording studio equipment rack

Enhancing Audio Experience

Designed with precision and versatility in mind, this case provides ample space and seamless integration for your Raspberry Pi 5 with IQaudio DAC Pro and DAC+ Sound Cards, enhancing your audio experience with unparalleled fidelity and flexibility.

Durable Build Quality

Constructed from sandblasted black anodized aluminum and a frame made of powder-coated steel, this case offers durability and stability, ensuring long-lasting protection for your Raspberry Pi. Assembly instructions are conveniently available via scanning the QR code on the product packaging, ensuring a straightforward and hassle-free setup process for users.

KKSB Pi 5 Case for DAC+/DAC Pro – on a hi-fi shelf between speakers

Some Examples of Possible Applications

High-Fidelity Audio Streaming Station: Transform your Raspberry Pi 5 into a high-fidelity audio streaming station by integrating the IQaudio DAC Pro Sound Card within the case. With support for up to 192 kHz 24-bit depth full HD audio, users can enjoy crystal-clear audio playback, making it ideal for streaming music, podcasts, or internet radio with exceptional clarity and fidelity.
Home Media Center: Create a sophisticated home media center with the Raspberry Pi 5 Case and IQaudio DAC Pro Sound Cards. Utilize the dedicated headphone amplifier and balanced outputs to connect to your existing audio equipment, enhancing your home theater experience with immersive surround sound and audiophile-grade audio quality for movies, TV shows, and multimedia content.
Professional Audio Production Setup: Empower audio enthusiasts and professionals alike with a versatile audio production setup using the Raspberry Pi 5 Case and IQaudio DAC Pro Sound Cards. With industry-standard RCA/Phono connectors and differential/balanced outputs, users can seamlessly integrate the Raspberry Pi into their studio environments for recording, mixing, and mastering music with precision and clarity.
Educational Audio Projects: Engage students and enthusiasts in educational audio projects by incorporating the Raspberry Pi 5 Case with IQaudio DAC Pro Sound Cards. From interactive sound installations to DIY synthesizers and digital audio workstations (DAWs), this versatile setup provides a platform for hands-on learning and experimentation in audio engineering, coding, and digital signal processing (DSP).

KKSB Pi 5 Case for DAC+/DAC Pro – opened case showing DAC sound card and cooler

Easy Access and Installation

The cover of the case is removable. You can set it aside to easily set up the cooler and install the sound card without having to struggle with limited space or closed corners.

This metal case for Raspberry Pi 5 includes an external start button, providing convenient access to power your Raspberry Pi without the need to open the case, ensuring ease of use and accessibility.

Access for a 40 GPIO cable on the side allows for easy connectivity with other devices and peripherals, simplifying setup and integration into various projects.

Compatible with Official Raspberry Pi Cooler

Designed to work seamlessly with the official Raspberry Pi cooler, this case for Raspberry Pi 5 ensures efficient cooling for optimal performance and reliability. This Raspberry Pi 5 also supports low-profile cooler with suitable dimensions to fit inside the case.

Stackable header, 18mm and 20mm spacers are included in the box. These spacers help to free up space between the cooler and the sound card mounted on top. The extra space allows proper airflow to complement heat dissipation. With plenty of ventilation slots on both side panels, heat dissipation is improved, allowing for optimal performance of your Raspberry Pi 5 even during intensive tasks or in warm environments.

KKSB Pi 5 Case for DAC+/DAC Pro – mounted on a DIN rail

Compatible with the KKSB DIN Rail Mount Clip

The base of the case is compatible with the KKSB DIN Rail Mount Clip (Not Included). This feature with lets you mount the case onto a 35mm Top HAT Rail.

This Raspberry Pi 5 Case for Raspberry Pi Sound Cards is designed in a way that you can use it in most settings without requiring hectic modifications. The case comes with rubber feet for better non-slip grip on most surfaces. You can use the two keyholes for wall mounting to save space.
