KKSB Jetson Orin Nano Super Developer Kit Case

Name: KKSB Jetson Orin Nano Super Developer Kit Case
Brand: KKSB Cases
SKU: 7350001162119
Price: 19.1 EUR
Availability: OutOfStock

€19,10

Sold out

SKU 7350001162119

The KKSB Jetson Orin Nano Super Developer Kit Case is a robust enclosure designed to protect and enhance the Jetson Orin Nano Super Developer Kit.

Sold-out

Technical Details

Compatibility: Jetson Orin Nano Super Developer Kit
Material: Sandblasted black anodized aluminum
Dimensions: 142 × 95 × 53 mm
Expansion Features: Cutout for 12 mm pushbutton (not included), 2 SMA antenna cutouts, 2 M3 threaded holes for KKSB Camera Holder
Mounting: VESA 75 interface (75 mm spacing); rubber feet for grip
Cooling Support: Ventilation slots above the heatsink

Worldwide shipping
EU delivery: Around 3-8 days, Outside the EU: Around 7-15 days.

Pay using Paypal or Bank Card
We also accept bank payment for larger orders

Durable Yet Professional Aluminum Build

The KKSB Jetson Orin Nano Super Developer Kit Case is a robust enclosure designed to protect and enhance the Jetson Orin Nano Super Developer Kit. Made from sandblasted black anodized aluminum, it combines durability with a professional matte finish.

Optimized Ventilation Above Heatsink

Ventilation slots above the heatsink support efficient airflow, while precision cutouts provide access for ports, connectors, and a 12 mm pushbutton (not included).

Some Examples of Possible Applications

Robotics and Automation – Integrate into robots, drones, or industrial automation units where secure housing and expansion options are needed.
Computer Vision and Smart Cameras – Use with external SMA antennas and camera holder support for vision-based projects.
IoT and Networking Gateways – Build gateways with antenna connectivity for extended wireless communication.
Kiosk and Embedded Systems – Install in panel-mounted setups for kiosks, digital signage, or industrial control panels.

VESA Mounting and Expansion Options

The case includes a VESA 75 interface with two plus-shaped holes for secure mounting on panels or brackets, while rubber feet provide stability on flat surfaces. It also features two SMA antenna cutouts and M3 threaded holes on top, making it easy to connect external antennas or attach the KKSB Camera Holder.

Note: Jetson Orin Nano Super Developer Kit, 12 mm pushbutton, SMA antennas, and KKSB Camera Holder are NOT included.
