Multi-Frequency IoT LoRa Node pHAT for Raspberry Pi
If you are looking for an upgraded HAT for Raspberry Pi to support the IoT LoRa Gateway then check out this Multi-Frequency IoT LoRa Node pHAT for Raspberry Pi. This hardware allows you to customize the LoRa node as per your requirements. You can put it to work in minutes. You have the option of customizing the network features by adding sensors and buttons. The Multi-Frequency IoT LoRa Node pHAT for Raspberry Pi features a pre-assembled RAKWireless (RAK811) supported by the SX1276 Long-Range technology.
Features of Multi-Frequency IoT LoRa Node pHAT for Raspberry Pi
- Supports KR 920MHz, AS923MHz, IN 865 (857MHz), AU 915 (928MHz), EU 863 (870MHz) and US 902 (928MHz)
- It is a Low-Power device that needs less than 50mA during transmission
- Features u.FL connector
- You can also integrate u.FL connector with external antennas
- Supports LoRaWAN connections
- LoRaP2P Modes supported
- It can also work with IoT LoRa Gateway HAT for Raspberry Pi
- The RAK811 LoRa Radio (fully-embedded LoRaWAN stack)
Compatible Raspberry Pi Boards with IoT LoRa Node pHAT
The IoT LoRa Node pHAT is compatible with Raspberry Pi PCs containing 40-Pin GPIO
- Raspberry Pi ZERO
- Raspberry Pi ZERO W
- Raspberry Pi 3 Model B
- Raspberry Pi 3 Model B+
- Raspberry Pi 2 Model B
- Raspberry Pi A+
- Raspberry Pi B+
What is IoT LoRa Gateway HAT?
IoT LoRa Gateway HAT is the hardware capable of receiving Long-Range Nodes (packets) and bridging these packets to the networks. Even if there are hundreds of nodes, the LoRa HAT can easily receive packets from all the nodes at the same time. In simple words, the IoT LoRa HAT functions like a WiFi router.
Items Included
- 1x RAK811 Pre-assembled
- Stickers
- 1x Info card
- 1x IoT LoRa Node pHAT for Raspberry Pi
- Mounting hardware
